Electric Control Series
Explosion-proof power distribution control cabinet

Brief introduction:


◆ Explosion-proof power distribution control cabinet has the explosion-proof technologies, such as positive pressure,explosion suppression, and encapsulation. Inside the cabinet, it can install various kinds of non-explosion-proof instrumentations, control instruments, display instruments, and low-voltage apparatus. It is widely used in explosive atmospheres (II Class B Area 2) in petroleum and chemical industry.
◆ Explosion-proof power distribution control cabinet will bring clean inactive gas into the plemum by the intelligent control system and pressure control system inside the cabinet. It will form micro-positive pressure to prevent the hazardous gases outside the cabinet from entering the cabinet to reach the explosion-proof purpose.
◆ Explosion-proof power distribution control cabinet has been recognized by explosion-proof inspection institutions and got explosion-proof certificate.

Performance parameters:


1.Environment temperature: -20~+45℃
2.Nominal voltage: 380V
3.Rated current: 1600A
4.Explosion-proof sign: ExpxdmⅡBT4
5.Protection grade: Ip54
6.Input gas source: clean inactive gas
7.Ventilation volume: 1~12m /h
8.Ventilation time: measured by the factory
9.Functional parameters
①Automatic ventilation before power supply. After ventilation,keep positive pressure in the cabinet automatically (500Pa±50Pa),auto power-supply.
②Positive pressure >850±50Pa, alarm and exhaust the air automatically
③Positive pressure <150±20Pa, supply the air automatically
④Positive pressure <80±30Pa, alarm and power off automatically
